temco 650-0598 Hubodometer – Accurate Mileage Tracking for Trailers & Trucks

🔍 Overview

The Stemco 650‑0598 is a rugged, mechanical hubodometer designed to deliver highly accurate mileage tracking at 500 revolutions per mile—perfect for maintenance scheduling, lease monitoring, or fleet management on heavy-duty trucks and trailers.

⚙️ Key Specifications

• Part Number: 650‑0598

• Revolutions per Mile: 500

• Measurement: Miles

• Display: 7‑digit mechanical odometer (non-resettable)

• Housing Diameter: Approx. 4⅖″ (4.75″)

• Mounting: Bracket or hub‑cap window compatible

🎯 Correct Tire Size Applications

According to Stemco’s calibration guide and several parts catalogs, the 650‑0598 is properly matched with the following tire sizes:

Note: Not suited for 16″ tires—earlier info was incorrect.

🔁 Cross-Reference & OEM Equivalents

Easily swap into existing systems using any of these equivalent part numbers:

• Veeder‑Root 777717‑500 / 777717‑494 (same calibration)

• Volvo OEM 8061486

• Stemco legacy labels: STE650‑0598, STM6500598

• Triseal 46500M (listed as compatible)
