Maintain the integrity and safety of your wheel assembly with this high-strength, metric serrated wheel stud. Engineered for precision and durability, this stud is designed for heavy-duty applications requiring a secure, press-fit installation.
| Attribute | Value |
|---|---|
| Type | Metric Serrated Wheel Stud |
| Thread (Wheel End) | M22 x 1.5 |
| Body Diameter | 0.975" |
| Total Length (A) | 3.750" |
| Wheel Thread Length (D) | 2.880" |
| Serration Length | 0.500" |
| Applications | Universal |
This wheel stud is a direct replacement for the following industry part numbers:
Euclid: E8988
Gunite: W1246
IHC / Navistar: 1655823C2
Meritor: R008988
Precision Threading: Features an M22 x 1.5 thread pitch for a reliable fit with compatible wheel nuts.
Secure Serration: The 0.500" serration length ensures a firm, non-slip grip within the hub assembly.
Heavy-Duty Construction: Built to withstand the high torque and load demands of commercial and universal applications.
Universal Fit: Designed for versatility across multiple vehicle makes and models using standard metric specifications.
Tech Tip: Always verify the body diameter and serration length against your existing hub requirements to ensure a proper press-fit. Over-sized or under-sized studs can lead to hub damage or wheel instability.
