| Attribute | Specification |
| Part Number | 13-1511L |
| Part Type | Wheel Lug Stud |
| Material | Carbon Steel |
| Bolt Grade | Grade 8 |
| Thread Size | 3/4"-16 |
| Thread Type | Fine |
| Thread Direction | Counterclockwise (Left) |
| Style | Non-Serrated Stud; Clipped Head |
| SAE or Metric | SAE |
| Color | Black |
| Weight | 0.440 lb |
| Selling Package Quantity | 5 |
| Package Contents | 5 Wheel Studs |
| Packaging Type | Bag |
These Dayton Wheel Lug Studs (Part Number 13-1511L) are high-quality, heavy-duty components engineered to meet the demanding standards of the automotive industry for strength, longevity, and safety.
Crucially, these studs feature a Counterclockwise (Left-Hand) direction, a 3/4"-16 fine thread, and a clipped, non-serrated head design for specific hub fitments.
Durable Carbon Steel: Manufactured from high-strength carbon steel that meets SAE automotive industry standards for exceptional strength and hardness (Grade 8).
Left-Hand Thread (LH): Features a Counterclockwise thread direction with a 3/4"-16 fine thread, critical for specific axle applications.
Corrosion Resistant: Subjected to extensive salt spray testing to ensure robust protection against rust and environmental corrosion.
Tensile Tested: Lug studs undergo industry-standard proof-load testing to guarantee the necessary strength and safety under high-stress conditions.
Unique Style:Non-serrated stud with a clipped head for specialized fitment requirements.
Trustworthy Quality: Backed by a dedicated team of professional engineers and quality control specialists in the United States.
| Measurement | Imperial (SAE) | Metric (Approx.) |
| Thread Size | 3/4"-16 | - |
| Threads Per Inch | 16 | - |
| Thread Diameter | 0.746 in | - |
| Thread Length | 1.243 in | - |
| Under Head Length | 2.94 in | - |
| Head Diameter | 1.166 in | - |
| Knurl Diameter | 0.000 in | - |
| Shoulder Diameter | 0.787 in | - |
| Shoulder Length | 1.168 in | - |
| Shoulder Thickness | 0.787 in | - |
| Shoulder Shape | Round | Round |
| Quick-Start Nose | No | No |
This Dayton Wheel Lug Stud (13-1511L) is an equivalent replacement for the following common part numbers:
| Name | Part Number | Notes |
| Euclid | E10213L | Wheel Stud |
| Meritor | R0010213L | Wheel Stud |
| Paccar | K03 | Wheel Stud |
| Paccar | SNAA010L | Wheel Stud |
| Other | 018003009 | - |
| Paccar Direct | W743 | - |
