Optimize your wheel-end safety with the Dayton Parts 13-2323R. This Grade 8 wheel lug stud is specifically designed for heavy-duty hub assemblies that utilize a Wedge Head seating system. Forged from premium carbon steel, it provides the superior clamping force and rotational resistance necessary for demanding commercial trucking applications.
Precision-engineered for a secure, non-serrated fit.
| Feature | Specification |
| Part Number | 13-2323R |
| Thread Size | 3/4-16 (Fine) |
| Thread Direction | Clockwise (Right) |
| Under Head Length | 3.375 in |
| Head Style | Wedge Head |
| Bolt Grade | Grade 8 |
| Weight | 0.56 lbs |
Thread Length: 1.7 in
Shoulder Length: 1.436 in
Shoulder Diameter: 0.784 in
Head Diameter: 1.465 in
Finish: Black (Corrosion Resistant)
High-Strength Carbon Steel: Meets SAE automotive industry standards for hardness and tensile strength, ensuring the stud maintains its integrity under extreme torque.
Corrosion Protection: Undergoes extensive salt spray testing to guarantee years of resistance against road salt, moisture, and chemical degradation.
Safety Verified: Each stud is tensile tested through industry-standard proof-load testing to ensure it meets structural requirements for heavy payloads.
Expert Support: Backed by a professional team of engineers and quality control specialists in the United States.
The 13-2323R is a direct replacement for several widely used OEM and aftermarket part numbers:
| Brand | Part Number | Notes |
| Meritor | R005924R | Wheel Stud |
| Meritor | 20X1334 | Wheel Stud |
| Meritor | 20X1464 | Wheel Stud |
| Meritor | 20X1977 | Wheel Stud |
| Euclid | E5924R | Wheel Stud |
