Upgrade your suspension with the ultimate durability of American-made polyurethane. The ATRO SP59-11006is a high-performance Spring Eye Bushing kit engineered to replace traditional threaded style bushings on Kenworth and PACCAR heavy-duty trucks. Unlike standard rubber, ATRO’s proprietary polyurethane is chemically resistant to grease, road salt, and environmental debris, ensuring a significantly longer service life and improved ride stability.
| Feature | Details |
| Part Number | SP59-11006 |
| Manufacturer | ATRO (Made in the USA) |
| Category | Suspension / Spring Eye Bushings |
| Outside Diameter (Ref) | 1 3/4" |
| Outer Sleeve Length | 4 1/16" |
| Pin Groove (C-C) | 6 5/16" |
| Shipping Weight | 3.05 lbs |
| UPC Code | 751354032871 |
| Installation Tool | PT00-53000 (Recommended) |
This comprehensive kit includes everything needed to upgrade your spring eye assembly:
(1) High-Performance Spring Eye Bushing
(2) SP1154M-04 Polyurethane Shims
(2) SP11006-03 Polyurethane Shims
This kit is a precision-engineered replacement for Kenworth and PACCAR systems, specifically designed for:
Kenworth Models: C500B, 550B, K100, K300, and T-Series (T300, T400, T450, T600, T800, T2000).
The SP59-11006 is an exact cross for Gaff 11753 and serves as a high-performance upgrade for the following:
Kenworth: B65-1006, B65-1017-001
PACCAR: B13-1000 (Bushing), B65-1008 (Pin)
Gaff: 11753 (Exact Cross)
Automann: MR836, MR836UB, MTB178, M5449, MKS59836
Dayton Parts: RB-295, TB77, 327-540
Dyco: DT1473
RoadForce: RF271507554
Replaces Threaded Styles: Specifically designed to replace older, high-maintenance threaded style bushings and pins.
Superior Resilience: ATRO polyurethane maintains its shape and alignment under extreme torsional loads where rubber typically fails.
Chemical Resistance: Impervious to oil, fuel, and road chemicals, preventing the "softening" or rotting associated with standard bushings.
Maintenance-Free: Self-lubricating properties reduce friction and eliminate the need for frequent greasing.
Installation Note: To ensure a proper press-fit and avoid damage to the polyurethane material, the use of the ATRO PT00-53000 installation tool is highly recommended.
