Optimize your suspension’s pivot points with the Atro EB38000. Designed for high-load Hendrickson and Granning suspensions, this beam end bushing replaces standard rubber with Atro’s signature high-durometer polyurethane. It is engineered to maintain alignment, reduce vibration, and provide maximum resistance to environmental contaminants.
| Feature | Details |
|---|---|
| Part Number | EB38000 |
| Category | Suspension (Beam End Bushing) |
| Length | 5 3/4" |
| Inside Diameter | 2 1/2" |
| Outside Diameter | 4 3/8" (Ref) |
| Sleeve Length | 4.25" (Outside Sleeve) |
| Shipping Weight | 7.72 lbs |
| UPC Code | 751354026955 |
| Qty Per Vehicle | 4 |
| Installation Tool | PT40000 |
Superior Material: Polyurethane construction outlasts rubber, maintaining its shape under extreme pressure without "cold flowing."
Zero Lubrication Required: Self-lubricating properties reduce maintenance intervals and eliminate the need for grease.
Enhanced Stability: Designed specifically for the Hendrickson 380-440 Series, ensuring your walking beam operates with precision.
Extreme Durability: Resistant to oil, salt, road chemicals, and extreme temperature fluctuations.
This bushing is a high-performance replacement for the following OEM and aftermarket parts:
Hendrickson: 45900, 29878-1, 45900-000L (380-440 Series)
Dayton Parts: 321-126, 321-242
Gaff: GAFF13553 (Exact Cross)
Euclid: E-2271, E-1341A
Automann: M1970UB, M1970HE
Ford: B8QH5873A
Granning: 1003 (T100A/AT, T200A Series)
