Keep your commercial rigs tracking straight and eliminate frequent suspension failures with this premium, American-made polyurethane straddle bushing from ATRO Engineered Systems. This component features ATRO's specialized High Articulation chemical formulation, engineered to handle intense suspension twisting and heavy torsional loads that quickly shred standard rubber bushings.
Crafted from solid heavy-duty polyurethane, it is entirely immune to oil, grease, road chemicals, and environmental dry-rotting, making it the ultimate maintenance-free upgrade for your fleet.
Vehicle System Fitment: Designed exclusively for Kenworth Airglide 200, 400, 460, and 690 suspension torque rods (specifically engineered for rod part numbers K195-474 and K195-472).
Rotational Constraint: This bushing is structurally fixed and does NOT rotate.
Required Shop Tooling: To prevent shell casing damage and ensure accurate seating, always install using ATRO service tool part number PT59-59110.
Component Category: Torque Rod / Straddle Bushings (High Articulation)
Material Type: Heavy-Duty Premium Polyurethane
Manufacturing Origin: United States (Proudly Made in the USA)
Center-to-Center (C-C) Dimension: 4-3/8 inches
Outside Diameter (Reference): 2-3/4 inches
Bolt Hole Size: 5/8 inch
Quantity Per Vehicle: 4 total required
Shipping Weight: 3.825 lbs
UPC Code: 751354036664
Verify your existing heavy-duty fleet parts catalog metrics match the original equipment and aftermarket numbers listed below:
Kenworth Factory OE: 836940, 227720, 839310 (Airglide 200/400/460/690 series)
Gaff: GAFF11729 (Exact Cross)
TRP Parts: TRB68250 (Exact Cross)
Dayton Parts: 321-369 / 321-369U (Near Cross)
Automann: TRB6825, TRB6825E
Euclid / Meritor: E-10303, E10303, R3010303 (Near Cross)
Neway: 90008265, 900-08-265
Haldex: CS70815, HD Plus KB920
Rockwell: R3010303
RoadForce: RF126000581
