ATRO MM96-62870-HT High-Temp Upper Engine Mount for Western Star

Product Overview

Protect your heavy-duty truck's powertrain assembly with the premium ATRO MM96-62870-HT High-Temperature Polyurethane Upper Engine Mount. Engineered and manufactured in the United States, this heavy-duty isolation component is custom-built to survive the most punishing underhood thermal environments.

Standard rubber engine mounts rapidly degrade, crack, and soften when exposed to continuous high-temperature heat cycles and underhood fluid leaks. ATRO’s custom-formulated, high-temperature polyurethane compound offers immense tensile strength and chemical resistance, meaning it won't collapse under heavy loads or rot from contact with grease, oil, and road chemicals.

System Compatibility Note: This upper position mount features a 3-inch center-to-center measurement and is explicitly engineered to be used in conjunction with two (2) MM96-62401-HT lower position mounts for a complete high-temperature installation station.

Specifications & Dimensions

• Shipping Weight: 0.75 lbs

• UPC Code: 751354028614

• Part Dimensions: Length: 6" | Width: 3" | Height: 3/4"

• Inside Diameter (ID): 5/8"

• Outside Diameter (OD) — Reference: 1 7/8" (nipple)

• Center-to-Center (C-C): 3"

• Material: Premium High-Temp Polyurethane

• Quantity Per Vehicle: 1 required

• Country of Origin: United States

Vehicle Application & Fitment Notes

This high-temperature upper engine mount delivers a precision drop-in fitment for several major heavy-duty and vocational truck configurations, serving as a direct upgrade path for:

• Western Star Trucks: Fits factory engine mounting stations (crosses to soft, hard, and alternative factory OE configurations).

Cross-Reference Guide

This part is a direct or high-quality performance upgrade to the following manufacturer and aftermarket part numbers:
