Description
This high-quality Firestone Air Spring is designed to provide reliable and efficient performance for your vehicle. It is compatible with a range of vehicles and features a Firestone brand name that is trusted for its durability and effectiveness. The part number for this air spring is 8829, and it is also cross-referenced with 1R12-405, 3934699, and 809709. This air spring is perfect for those who need to replace their current suspension system or for those who want to upgrade their vehicle for better performance. It is easy to install and is designed to work seamlessly with your vehicle’s air suspension system.
| Firestone Bellows# | 1T15M-6 |
| Contitech Bellows# | 9 10-17.5 |
| Load (Lbs) @80 PSI | 5900 |
| Load (Lbs) @100 PSI | 7500 |
| Natural Freq. (CPM) | 71 |
| Design Height (In) | 11.00 |
| Bottom Plate Type | Plastic |
| Top Plate Hole/Stud Qty | 2 |
| Top Plate Dia. (A) | 9.00 |
| Top Plate C to C Dia. (B) | 5.50 |
| Bottom Plate Hole/Stud Qty | 1 |
| Bottom Plate Dia. (C) | 10.00 |
| Bottom Plate C to C Dia. (D) | N/A |
| Bottom Part # | |
| Bumper | No |
| Bracket | |
| Min. Height | 6.50 |
| Max. Height | 22.10 |
| Max. Dia. | 12.60 |
